J-140 HD/SD ENCODER IP
4in1 with IP/ASI output
Features

Specifications


OVERVIEW


High-Tech transcoding HD/SD Encoder to Transport Stream (TS) over IP or ASI as output
4 video encoders H.264/1080p Full HD built-in with professional multiplex technology
Unicast and Multicast IP addressing
10/100 Base-T Transmission
A/V input for backup signal source

Features


Support H.264 and main video resolutions 1080 i/p, 720p, 576 i/p, 480i/p
HDMI and CVBS input available for HD and SD encoding
Front plate LCD to read channel status
PMT, Video/Audio PID, Service/Network Name programmable
Friendly configuration & management control through front panel or network
GENERAL

Power Supply
100-240V AC, 50/60Hz, DC 12V / 2A
Packing
5 inner boxes (10 modules)/17Kgs/ 2.54 cuft/ Carton
