WFR-6600L


Features
Specifications
  CATV OPTICAL TRANSMITTER

Features


870MHz RF bandwidth
1310 and 1550nm optical operation
Easily accessible test points
Front panel received optical power rang LED indicator
Optional dual receiver for optical redundancy with A/B switching 　
SPECIFICATIONS

Optical Parameters

Photodiode type InGaAs Pin
Optical wavelength 1310 ± 20nm; 1550 ± 20nm
Optical power input range +3 to -6dBm
Equivalent input noise current density 8.5 pA/Hz
Number of receiver unit/module 1 (A/B switch)

RF Parameters

Operating bandwidth 45 to 870MHz
RF output impedance 75ohm (unbalanced)
RF output return loss ≦ -16dB
RF connector F type female
RF output level (analog) 36 dBmV/ch @-3dBm input (when OMI/ch =3.6%)
Gain control range 10dB
Slope adjustment -1 to +2 dB
Flatness ±1 dB
Test point -20 dB refer to output port
Pilot tone for AGC @10.7 MHz ± 50KHz

Electrical / Environmental / Mechanical

Control interface RS485
Power supply 90 to 260 VAC, 50/60 Hz, 15W(Max.)
Operating temperature 0 to 50°C
Storage temperature -20 to 70°C
Relative humidity 85% max
Dimensions 350 D x 485 W x 45 H (mm)
Weight 4.5kg
