WFA-5600L


Features
Specifications
  CATV OPTICAL TRANSMITTER

Features


1 U, 19 inches rack housing, front panel LCD display
+13 to +23 dBm in full output power range
High reliability 980 / 1480 nm pump laserdiode
High gain, and low noise figure
Microprocessor controlled
Advanced heat sink design

SPECIFICATIONS

Optical Parameters

Operating wavelength 1540 to 1560nm
Optical input power range -5 to +10dBm
Optical output power 13 to 23dBm(for input power of 0 dBm at 1550nm)
Polarization sensitivity 0.3dB
Noise Figure (for input power of 0 dBm at 1550nm)
13~18dBm 4.5 dB (typical)
19~20dBm 5.5dB (typical)
21~23dBm 5.5dB (typical)
Optical input/output isolation
13~18dBm 25/25 dB (Min.)
19~23dBm 25/45 dB (Min.)
Polarization mode dispersion 0.5ps (Max.)


Electrical / Environmental / Mechanical

Control interface RS 485
Power supply 90 to 260 V AC, 50/60 Hz, 50 W (Max.)
Operating temperature 0 to 50 ° C
Storage temperature -20 to 60 ° C
Relative humidity 85% Max
Dimensions 350 D x 485 W x 45 H (mm)
Weight 6kgs
